Spherical Disc Butterfly Valves: Precision for Pharma & Chemical Processing
The Spherical Disc Butterfly Valve (often referred to as a Split Body or Pharma Butterfly Valve) features an investment-cast disc with a spherical seating surface. This unique geometry allows for a more consistent seal with lower friction compared to standard discs, ensuring a long working life and high performance in vacuum or pressurized conditions.
The FlowBiz Structural Advantage
- Forged & Fit Design: Engineered for minimal maintenance and maximum structural integrity.
- Bi-Directional Sealing: Provides a bubble-tight seal against pressure or vacuum up to PN10 / PN16 ratings.
- PTFE Soft Seat: The body is lined with a high-grade PTFE (Teflon) seat, enabling smooth operation at temperatures up to 210°C (Standard rating up to 180°C).
- Slim Seal Construction: The investment-cast "slim seal" wafer design minimizes the valve's footprint, making it ideal for compact pharmaceutical skids and powder handling systems.
Technical Specifications
FlowBiz ensures every valve meets international pharmaceutical and industrial standards:
Feature | Technical Detail |
Size Range | 2" to 18" (50mm – 450mm) |
Design Standard | API 609 |
End Connection | Wafer Type (Fits between flanges) |
Body MOC | WCB / CF8 / CF8M / CF3 / CF3M |
Disc Material | Stainless Steel CF8 / CF8M (Mirror Polished) |
Seat/Seal Material | PTFE (Chemically Inert) |
Max Temperature | 180°C (Standard) / Up to 210°C (Special Application) |
Core Industrial Applications
The FlowBiz Spherical Disc Valve is the definitive choice for:
- Pharmaceuticals: Handling dry bulk materials, powders, and aseptic fluids.
- Food & Beverage: Processing dairy, juices, and ingredient mixing.
- Chemical & Petrochemical: Managing corrosive media and refining processes.
- Water & Waste Water: High-efficiency flow management in treatment plants.
Your Global Sanitary Valve Partner
As a top-tier manufacturer, FlowBiz Exports delivers "Make in India" precision to global markets. Our butterfly valve range is diverse, ensuring a solution for every flow challenge:
- Our Full Butterfly Range: Double Flange, Offset Disc, MS Fabricated, Metal Seat, Triple Offset, PTFE Seat, Damper, and Lug Type Butterfly Valves.
- Global Presence: Trusted by industry leaders in Dubai, Turkey, Africa (Nigeria, Kenya, South Africa), Bangladesh, Thailand, and Vietnam.
Is your production line struggling with material buildup or seat wear in powder handling?
Upgrade to the FlowBiz Spherical Disc Butterfly Valve for a smoother, cleaner, and more reliable process. Contact our technical team today for a sizing consultation and material compatibility check.
