The Essential Industrial Trio: Gate, Globe, and Swing Check
These three valve types often work in tandem within a single pipeline system. Engineered for ruggedness and durability, they are designed to handle the thermal and mechanical stresses of ASME Class 150 to Class 2500 applications.
1. Cast Steel Gate Valves (API 600)
Designed for primary isolation, these valves feature a flexible wedge and Outside Screw and Yoke (OS&Y) construction. The bolted-bonnet design ensures ease of maintenance and a secure seal.
- Best for: Full-bore, "on-off" service with minimal pressure drop.
2. Cast Steel Globe Valves (BS 1873)
While the gate valve handles isolation, the globe valve is the master of throttling and regulation. Its internal S-shaped flow path allows for precise control of flow and pressure.
- Best for: Modulating flow and frequent operation.
3. Cast Steel Swing Check Valves (BS 1868)
Often referred to as Non-Return Valves (NRV), the swing check valve uses a weighted disc that "swings" open with forward flow and automatically slams shut to prevent backflow.
- Best for: Protecting pumps and compressors from flow reversal.
Technical Specifications & Standards
FlowBiz valves are manufactured to outperform in extreme conditions, utilizing premium cast steel and specialized alloys.
Feature | Technical Detail |
Design Standards | API 600 (Gate), BS 1873 (Globe), BS 1868 (Check) |
Pressure Ratings | ASME Class 150, 300, 600, 900, 1500, 2500 |
Body Materials | ASTM A216 WCB, WCC, LCB, LCC, CF8, CF8M |
End Connections | Flanged Ends (FF, RF, RTJ) or Buttweld Ends |
Bonnet Design | Bolted Bonnet (Standard) or Pressure Seal (High Pressure) |
Trim Selection | API 600 Trim Standards (Stellite, 13% Cr, SS316) |
The FlowBiz Manufacturing Advantage
- Rugged Durability: Every valve is factory-engineered for a long service life, reducing the Total Cost of Ownership (TCO).
- Tight Sealing: Precision-lapped seating surfaces ensure bubble-tight shut-off for gate and check valves.
- Ease of Operation: High-efficiency handwheels and gear operators reduce the torque required for manual operation.
- Full Range Support: FlowBiz is a single-source supplier for all flow control accessories, including Needle Valves, IBR Valves, and PFA-Lined Valves.
Serving Critical Global Sectors
FlowBiz brand valves are the backbone of major infrastructure and energy projects across India, Dubai, Turkey, Africa, Southeast Asia, and beyond. * Oil & Gas: Upstream and downstream refinery isolation.
- Power Plants: High-pressure steam and feed-water cycles.
- Chemical Industry: Handling corrosive and high-temperature reagents.
- Water Treatment: Large-scale municipal and industrial distribution.
Is your facility undergoing a high-pressure upgrade or maintenance turnaround?
Trust the rugged reliability of the FlowBiz API 600 / BS Family. Contact our technical team today for a formal quote, general arrangement (GA) drawings, and assistance with trim material selection for your specific media.
