Triple Offset Design: The "Zero Leakage" Engineering
The Triple Offset Butterfly Valve (TOV) represents the pinnacle of valve geometry. Unlike concentric or double offset designs, the TOV incorporates three distinct offsets that eliminate seat friction and wear:
- First Offset: The shaft is located behind the sealing surface.
- Second Offset: The shaft is located to one side of the pipe centerline.
- Third Offset (The Geometric Innovation): The seat and disc seal are machined into an inclined conical profile.
The Result: Frictionless Sealing
This geometry creates a "cam-action" closure. The disc only contacts the seat at the final point of closing. This eliminates rubbing, reduces operating torque, and allows for a high-integrity metal-to-metal seal that is ideal for high-temperature and fire-safe applications.
Technical Specifications (2026 Wafer Series)
The Wafer Type design is preferred for its compact "face-to-face" dimensions, making it easy to install between existing pipe flanges while saving significant weight and space.
Feature | Technical Detail |
Body Material | WCB, CF8M (SS316), LCC, Duplex Steel |
Seat Material | Stellite Hard-faced / Laminated SS+Graphite |
Pressure Class | ASME Class 150#, 300#, 600# |
Temperature | Cryogenic to 600°C+ |
Design Standard | API 609 / ASME B16.34 / API 607 (Fire-Safe) |
End Connection | Wafer (Short Pattern) |
Strategic Industrial Applications
1. Oil & Gas (Refineries & Petrochemicals)
Essential for high-temperature hydrocarbon service where fire-safe certification (API 607) is a mandatory safety requirement.
2. Power Generation & Steam Service
The metal-to-metal seat thrives in high-pressure steam lines and condensate systems where soft seats would melt or degrade.
3. Chemical Processing
The triple offset design handles aggressive chemicals and light vacuum applications with superior sealing integrity.
4. Cryogenic Service
Engineered with specialized materials to maintain a bubble-tight seal in liquid nitrogen and LNG applications.
FlowBiz Exports: Serving India and the Global Market
FlowBiz Exports is a dominant Triple Offset Valve manufacturer, providing IBR-certified and fire-safe solutions across major industrial corridors:
- Gujarat Manufacturing: Trusted supplier in Vapi, Dahej, Ankleshwar, Bharuch, and Ahmedabad.
- Maharashtra Presence: Leading manufacturer for Mumbai, Pune, Nashik, and Nagpur.
- Global Footprint: Exporting precision "Make in India" valves to Dubai, Turkey, Africa, and Southeast Asia.
Does your system require 100% shut-off in extreme thermal cycles?
Upgrade to the FlowBiz Triple Offset Wafer Type Butterfly Valve. Innovation is our middle name, and our fire-safe, metal-seated valves are the proof. Contact our technical team today at +91 9016 989898 for a formal quote and GA drawings.
