Forged Steel Globe Valves: High-Pressure Precision
The FlowBiz Forged Steel Globe Valve is the industry's first choice for throttling and frequent operation in small-bore, high-pressure piping. Adhering to API 602 and ISO 15761 standards, these valves are designed for "zero-leakage" performance in the most demanding utility and process lines.
Key Engineering Features
- Forged Body Integrity: Manufactured from solid forged blocks (A105, F304, F316, F11, F22), eliminating the risk of porosity common in cast valves.
- Outside Screw & Yoke (OS&Y): The stem threads are external to the fluid media, preventing corrosion and facilitating easy lubrication for smooth operation.
- Bonnet Versatility: Available in Bolted Bonnet for ease of maintenance or Welded Bonnet for permanent, leak-proof security in high-vibration systems.
- Renewable Seats: Features hard-faced (Stellite) seating surfaces to resist erosion and wire-drawing during high-velocity throttling.
Technical Specifications & Product Range
FlowBiz offers one of the most comprehensive ranges of forged globe valves in the industry, covering a wide spectrum of pressure classes.
Feature | Details |
Design Standards | API 602 / BSEN ISO 15761 / ASME B16.34 |
Testing Standards | API 598 |
Body Materials | ASTM A105, A182 F304/F316, F11, F22, LF2 |
End Connections | Socket Weld (SW), Screwed (NPT/BSP), Buttweld (BW), Flanged |
Bore Type | Full Bore / Standard Bore |
Pressure Class & Size Range
- Class 150: 1½" (40mm) to 36" (900mm)
- Class 600: ½" (15mm) to 2" (50mm)
- Class 800: ¼" (8mm) to 2" (50mm)
- Class 1500: ½" (15mm) to 1½" (40mm)
- Class 2500: ½" (15mm) to 1" (25mm)
Strategic Supply Chain Across India
As the leading Forged Steel Globe Valve manufacturer in India, FlowBiz ensures rapid delivery and technical support across all major industrial hubs:
- Gujarat: Ahmedabad, Vapi, Valsad, Surat, Gandhidham, Kutch, Ankleshwar, Bharuch.
- Maharashtra: Mumbai, Nashik, Pune, Thane, Aurangabad, Satara, Sangli, Nagpur, Kolhapur.
- Madhya Pradesh: Indore, Dewas, Bhopal.
- South India: Chennai, Coimbatore, Salem.
Industrial Applications
- Refineries: Handling high-pressure hydrocarbons and catalyst lines.
- Power Plants: Ideal for high-pressure steam drains, vents, and bypass lines.
- Chemical Processing: Managing aggressive reagents where material purity is critical.
- Oil & Gas Upstream: Reliable isolation for wellhead and manifold systems.
Does your project involve high-pressure steam or volatile fluids that require the structural security of forging?
Trust the engineering excellence of FlowBiz Exports. Contact our technical team today at +91 9016 989898 for a formal quote, material test reports (MTRs), or assistance with trim selection.
