MS Fabricated Butterfly Valves: Engineering Excellence
Unlike cast valves, our MS (Mild Steel) Fabricated valves are constructed using advanced welding and machining techniques. This allows for a lighter and stronger construction, making them easier to transport and install, especially in large-diameter applications where weight is a critical factor.
Salient Features of the FlowBiz Design
- Self-Energizing Disc Seal: Our innovative seal design utilizes the system's own pressure to enhance the sealing force. This ensures bi-directional, bubble-tight sealing, preventing leaks regardless of the flow direction.
- Assured Sealing to Atmosphere: Engineered with high-integrity gland packing and O-rings to ensure zero leakage to the outside environment, protecting both your personnel and the surrounding infrastructure.
- Lower Operating Torque: The streamlined disc profile and maintenance-free bearings significantly reduce the force required to open and close the valve, allowing for smaller, more cost-effective actuators.
- Longer Service Life: The combination of precision fabrication and high-quality protective coatings (such as Epoxy or PU) ensures high resistance to corrosion and wear over decades of operation.
Technical Specifications (2026 Series)
Feature | Technical Detail |
Body Material | MS Fabricated (IS 2062 Gr. B / ASTM A36) |
Disc Material | MS Fabricated / Stainless Steel (CF8/CF8M) |
Seat Material | EPDM / Nitrile / Viton / Silicon |
Shaft Material | Stainless Steel (SS410 / SS304 / SS316) |
Pressure Rating | PN 6, PN 10, PN 16 (Higher on request) |
Size Range | 200mm (8") to 3000mm (120") |
Standard | AWWA C504 / IS 13095 / BS 5155 |
Strategic Industrial Applications
1. Water Works & Irrigation
The preferred choice for massive water mains and canal distribution networks where large-diameter valves must be both reliable and easy to handle.
2. Cooling Water Systems
Ideal for power plants and refineries where large volumes of water are circulated at low to medium pressures.
3. HVAC & Firefighting
Used in high-rise infrastructure and commercial complexes for reliable isolation of chilled water and fire protection lines.
4. Sewage & Effluent Handling
The smooth, full-flow design prevents the accumulation of solids, making it suitable for treated sewage and industrial effluent discharge.
Serving Mumbai and Beyond
FlowBiz Exports is the trusted name for Valves in the Mumbai Area, providing rapid supply to Thane, Navi Mumbai, and the Konkan belt. Our fabricated solutions are also exported to global markets including Dubai, Africa, and Southeast Asia, where "Make in India" quality is highly valued.
Are you looking for a custom-sized valve that combines the strength of steel with the precision of a bubble-tight seal?
Experience the FlowBiz difference. Contact us today for more details and get a quick quote for your specific project requirements.
