Double Eccentric Design Offset Disc Wafer Butterfly Valve: Engineering Excellence

In critical industrial piping, the standard concentric butterfly valve often suffers from rapid seat wear due to constant friction. The FlowBiz Double Eccentric (Double Offset) Butterfly Valve is the advanced solution to this challenge. By utilizing a sophisticated offset disc geometry, the disc "cams" into the seat, significantly reducing friction, lowering operating torque, and extending the valve's service life.

As a leading manufacturer and exporter in India, FlowBiz Exports delivers 100% quality-assured wafer-type butterfly valves that provide bubble-tight shut-off for water, oil, gas, and chemical process lines.

Understanding the Double Offset Engineering

The "Double Eccentric" design refers to two specific offsets in the valve's architecture that improve performance:

1. First Offset: The shaft is located behind the centerline of the sealing surface, allowing the disc to provide a full 360-degree sealing contact.
2. Second Offset: The shaft is located slightly to one side of the pipe centerline. This ensures that the disc moves away from the seat almost immediately upon opening, minimizing mechanical wear.

Core Advantages:

• Reduced Friction: The disc only contacts the seat during the final degrees of closure, preventing seat deformation.
• Lower Torque Requirements: The "cam-action" design allows for smaller, more economical pneumatic or electric actuators.
• Bi-Directional Sealing: Engineered to hold pressure firmly in both directions.
• High-Cycle Durability: Ideal for automated systems requiring frequent operation.

Technical Specifications & Manufacturing Standards

FlowBiz valves are a "stalwart" of reliability, manufactured to the following rigorous benchmarks:

• Design Standard: API 609 / ASME B16.34
• Body Type: Wafer (Ultra-compact for easy installation between flanges)
• Pressure Rating: PN10, PN16, Class 150, Class 300
• Seating Materials: PTFE, EPDM, VITON, or Metal-to-Metal for high-temperature service.
• Operation: Available with Manual Lever, Gear Operator, or Pneumatic/Electric Actuation.

Global Supply & Manufacturing Reach

FlowBiz Exports is recognized as the best manufacturer and supplier for key sectors in India and across the international landscape.

Domestic Infrastructure Support:

We provide rapid fulfillment to all major industrial hubs:

• Gujarat: Ahmedabad, Vapi, Valsad, Bharuch, Ankleshwar, Gandhidham, Dahej, and Sanand.
• Maharashtra: Mumbai, Pune, Nashik, Nagpur, Aurangabad, Pimpri, and Ambernath.
• Additional Hubs: Indore, Bhopal, Chennai, Coimbatore, and Salem.

International Export Markets:

Our high-performance valves are trusted by overseas customers in Dubai, Turkey, Africa, Nepal, Uganda, Nigeria, Kenya, Bangladesh, Thailand, Vietnam, South Africa, Morocco, Tanzania, Mozambique, Congo, and Rwanda.

Do you need a valve that offers a longer life cycle and lower maintenance costs?
