Single Piece Ball Valve

Single-Piece Design Ball Valve Manufacturer: FlowBiz Exports

The FlowBiz Single-Piece Ball Valve is defined by its monolithic body construction. Unlike two-piece or three-piece valves, this design features a body and end connection formed from a single block of material. The internal trims (ball and seals) are inserted through the end connection, eliminating a major body joint and significantly reducing potential leak paths.

Reduced Bore Efficiency

These valves utilize a Reduced Bore (Reduced Port) configuration. A ball orifice one size smaller than the pipe diameter is used, which allows the valve to be more compact, cost-effective, and structurally solid while maintaining efficient flow control for hazardous liquids.

Technical Specifications & Compliance

FlowBiz ensures all ball valves meet rigorous international safety and fire-testing standards:

Feature

Specification Details

Design Standard

ISO 17292

End Connections

ASME B16.5 (Flanged)

Face-to-Face

ASME B16.10

Pressure Testing

ISO 5208 / API 598

Fire Safety

ISO 10497 / API 607 (Fire-Safe Design)

Media Suitability

WOG (Water, Oil, Gas), Toxic Chemicals, Hazardous Fluids

Key Features & Advantages

  • Superior Leak Protection: The single-piece body eliminates a secondary leak path (the body-to-tailpiece joint), making it the safest option for toxic, hazardous, or high-vacuum services.
  • Economical & Stalwart: Its simplified, rugged design provides maximum structural integrity at a lower cost compared to multi-piece flanged valves.
  • Fire-Safe Design: Compliant with API 607, ensuring that in the event of a fire, the valve maintains its seal to prevent the spread of flammable media.
  • Compact Footprint: The reduced bore design allows for a smaller overall valve profile, saving space in tight industrial skids and manifolds.
  • Durable Trims: High-quality balls and seats are inserted with precision, ensuring smooth torque and long-term cycle life even in chemical-intensive applications.

Strategic Industrial Applications

  • Chemical Processing: Handling aggressive acids and hazardous reagents.
  • Oil & Gas (WOG): Reliable service in Water, Oil, and Gas transmission where safety is paramount.
  • Toxic Media Handling: Preferred for lines carrying volatile organic compounds (VOCs).
  • Refineries: Ideal for small-bore utility and process lines requiring fire-safe certification.

Pan-India Supply & Support

Based in Mumbai, FlowBiz is recognized as a leading manufacturer and exporter, supplying WOG Ball Valves across:

  • Gujarat: Ahmedabad, Vapi, Surat, Gandhidham, Kutch, Ankleshwar, and Bharuch.
  • Maharashtra: Mumbai, Pune, Thane, Nashik, and Nagpur.
  • Central & South India: Indore, Bhopal, Chennai, Coimbatore, and Salem.

Contact Information

Consult the FlowBiz technical team for MOC (Material of Construction) options and quick quotes:

Request Your Quick Quote Today!

Secure your most critical process lines with the "Stalwart" engineering of FlowBiz Single-Piece Ball Valves. We provide Easy and Quick Quotes at factory prices for domestic infrastructure and global chemical exports.

Contact FlowBiz Exports Pvt. Ltd. now – Your premier partner for Single-Piece Design Ball Valves.
