Wafer Type Ball Valve Manufacturer: FlowBiz Exports
The FlowBiz Wafer Type Ball Valve is a "compact space" solution designed to be sandwiched between two pipeline flanges. Featuring inbuilt flange tapping, it is secured using through-bolts that span the width of the valve. This design eliminates the bulky flanges found on standard valves, making it the most economical and space-efficient choice for modern industrial skids and manifolds.
Technical Specifications & Compliance
FlowBiz wafer valves are manufactured to rigorous international standards to ensure safety and performance in high-pressure environments:
Feature | Specification Details |
Size Range | 1 inch to 4 inches (25 mm to 100 mm) |
Pressure Class | ASME Class 150 to Class 900 |
Design Type | Single-Piece Design / Floating Ball Type |
Construction | Cast or Forged Materials |
Temperature | Dependent on seat material (PTFE, RPTFE, PEEK) |
Engineering Standards:
- Design & Manufacturing: ASME B16.34 / API 6D
- Flange Conformity: ASME B16.5 Class 150
- Inspection & Testing: API 598 / FCI-70-2 / BS EN 12266-1
- Fire Safety: API 607 / BS 6755
Key Features & Advantages
- Space & Weight Optimization: The ultra-slim wafer design occupies significantly less area than flanged valves, reducing the structural load on the piping system and lowering shipping costs.
- Cost-Effective Performance: By using less raw material for the body without compromising the pressure rating, these valves provide a high-performance alternative at a lower price point.
- Simplified Installation: The inbuilt tapping allows for quick alignment between flanges, reducing labor time during plant assembly.
- Robust Construction: Available in both cast and forged variants, these valves are capable of handling high-pressure applications up to Class 900.
- Reliable Sealing: Despite the compact size, these valves provide a bubble-tight shut-off (FCI-70-2 Class VI) suitable for various industrial media.
Strategic Industrial Applications
- Chemical Processing: Compact skids for chemical dosing and distribution.
- Oil & Gas: High-pressure utility lines where space is at a premium.
- Water Treatment: Efficient isolation for filtration and reverse osmosis units.
- HVAC Systems: Chilled water and steam distribution in commercial buildings.
- Pulp & Paper: Handling non-abrasive process fluids in tight pipeline layouts.
Pan-India Supply Network
FlowBiz Exports is the leading manufacturer of wafer-type ball valves, serving industrial hubs across:
- Maharashtra: Mumbai, Pune, Thane, Nashik, Nagpur, and Aurangabad.
- Gujarat: Ahmedabad, Vapi, Surat, Gandhidham, Bharuch, and Ankleshwar.
- South & Central India: Chennai, Coimbatore, Salem, Indore, and Bhopal.
Contact Information
Consult the FlowBiz technical team for material compatibility charts and quick quotes:
- Website: www.flowbizexports.com
- Email: info@flowbizexports.com
- Contact: +91 8879358242 / +91 9016989898
Request Your Quick Quote Today!
Upgrade to the compact efficiency of FlowBiz Wafer technology. We provide Easy and Quick Quotes at factory prices for both domestic infrastructure and international exports.
Contact FlowBiz Exports Pvt. Ltd. now – Your premier partner for Wafer Type Ball Valves.
