High-Performance 3-Piece Forged Steel Ball Valves by FlowBiz
When process lines demand tight shut-off under high-pressure and high-temperature conditions, standard cast valves often fall short. FlowBiz Forged Steel Ball Valves (3-Piece Construction) are engineered to provide maximum structural strength, zero porosity risks, and dependable flow control across extreme operational environments.
Featuring a heavy-duty three-piece body design with Screwed (BSP / NPT / BSPT) and Socket Weld (SW) end connections, these valves allow easy inline maintenance and seat replacement without removing the valve ends from the piping line. Equipped with ergonomic, branded lever handles and positive locking indicators, FlowBiz ball valves guarantee smooth quarter-turn operation and dependable performance.
Technical Specifications & Features
FlowBiz 3-piece forged steel ball valves are built to meet rigorous international piping standards:
- Design Construction: 3-Piece Bolted Body Design for quick inline servicing.
- End Connections: Screwed Ends (BSP / NPT / BSPT Threaded), Socket Weld (SW) Ends, and Flanged Ends on request.
- Manufacturing Material: Forged Carbon Steel (ASTM A105) or Stainless Steel (ASTM A182 F304 / F316).
- Pressure Rating: Suitable for High-Pressure Class ratings (Class 800 / Class 1500 / Class 2500).
- Operation: Heavy-duty lever handle with red PVC sleeve for firm grip and clear ON/OFF orientation.
- Sealing: High-grade PTFE / CFT / PEEK seats providing zero-leakage shut-off.
Technical Overview Table
Technical Parameter | Specification Details |
Manufacturer | FlowBiz Exports Pvt. Ltd. |
Valve Type | Forged Steel Ball Valve |
Body Construction | 3-Piece Bolted Body |
End Connections | Screwed (Threaded BSP / NPT) & Socket Weld (SW) |
Size Range | 1/2" (DN15) to 2" (DN50) |
Pressure Class | Class 800 # / 1500 # |
Body Material | Forged Steel (ASTM A105 / A182 F304 / F316) |
Seat Material | PTFE / RPTFE / CFT / PEEK |
Testing Standards | API 598 / BS EN ISO 17292 |
Key Applications Across Industries
FlowBiz Forged Steel Ball Valves deliver long service life in critical high-pressure utilities:
- Oil & Gas Pipelines: Reliable isolation for high-pressure gas headers and threaded oil manifolds.
- Chemical & Petrochemical Lines: Safely isolates aggressive chemicals, solvents, and fuels.
- High-Pressure Steam Systems: Installed on boiler feed lines, steam traps, and blowdown systems.
- Hydraulic & Pneumatic Skids: Compact screwed end design provides fast, positive shut-off in automated machinery and hydraulic lines.
Why Choose FlowBiz Exports Pvt. Ltd.?
FlowBiz is a trusted leader in industrial valve manufacturing, combining precision forging with rigorous quality assurance testing:
- 100% Factory Tested: Every valve undergoes shell hydro-testing and high-pressure seat-leak verification.
- Easy Maintenance: 3-piece swing-out design reduces plant maintenance overheads and downtime.
- Traceable Quality: Built with certified raw materials ensuring resistance to thermal shock and mechanical stress.
Reliable Supply Chain Across India & Abroad
FlowBiz serves as a trusted Forged Steel Ball Valve manufacturer with a massive distribution network. We provide rapid delivery and local support in:
- Gujarat: Key hubs including Ahmedabad (Odhav, Vatva, Naroda, Sanand), Vapi, Bharuch, Dahej, Gandhidham, and Surat (Hazira, Sachin).
- Maharashtra: Major industrial centers such as Mumbai, Pune, Nashik, Nagpur, and Aurangabad.
- International: Proudly exporting high-pressure valve solutions to clients across Africa and global markets.
