High-Performance Jacketed Ball Valves by FlowBiz – Temperature-Controlled Flow Isolation
In handling highly viscous fluids, molten polymers, bitumen, resins, sulfur, and heavy oils, temperature drops can cause process media to solidify, clog, or freeze inside the valve body. FlowBiz Jacketed Ball Valves are specialized flow isolation valves featuring a welded outer heating jacket designed for circulating steam, hot water, heat transfer oil, or media fluids to maintain precise process temperatures.
Manufactured with a full-coverage jacket encompassing the valve body from flange-to-flange, FlowBiz jacketed ball valves eliminate thermal cold spots, ensure smooth quarter-turn operation, and prevent media crystallization during production shut-downs or continuous operations.
Technical Specifications & Features
FlowBiz jacketed ball valves are custom-engineered for heavy-duty thermal and industrial piping systems:
- Jacket Construction: Weld-fabricated Full Jacket / Partial Jacket surrounding the main valve body.
- Jacket Connections: Threaded (NPT / BSP) or Socket Weld heating fluid inlet/outlet ports.
- Heating Medium: Suitable for Steam, Thermic Fluid / Thermal Oil, and Hot Water circulation.
- End Connections: ANSI Class 150# / 300# Oversized Flanges (to match standard jacket piping clearance).
- Operation: Manual lever operation with ergonomic red PVC sleeve and top mounting pad.
- Sealing & Trim: High-temperature PTFE / CFT / PEEK seats providing bubble-tight shut-off.
Technical Overview Table
Technical Parameter | Specification Details |
Manufacturer | FlowBiz Exports Pvt. Ltd. |
Product Type | Jacketed Ball Valve (Steam / Thermal Oil Heated) |
Body Construction | 2-Piece / 3-Piece Flanged Body with Outer Welded Jacket |
Jacket Port Options | 1/2" to 1" NPT / BSP Threaded Ports |
Pressure Class | Core Valve: Class 150# / 300# | Jacket Rating: 10 to 20 Bar |
Body Material | Cast Carbon Steel (WCB) / Stainless Steel (CF8 / CF8M) |
Jacket Material | Carbon Steel / SS304 / SS316 |
Seat Material | PTFE / RPTFE / CFT / Graphite / PEEK |
Key Applications Across Industries
FlowBiz Jacketed Ball Valves are vital for handling temperature-sensitive and high-viscosity media:
- Bitumen & Asphalt Plants: Maintains liquid state in road construction and roofing asphalt lines.
- Polymer & Resin Processing: Prevents solidification of molten polymers, synthetic resins, and adhesives.
- Refineries & Sulfur Recovery: Prevents elemental sulfur from freezing on internal ball surfaces.
- Food & Pharmaceutical Processing: Used for transferring chocolate, glucose, tallow, and wax lines.
Why Choose FlowBiz Exports Pvt. Ltd.?
FlowBiz provides thermal-engineered valve designs built for maximum reliability:
- Eliminates Cold Spots: Continuous jacket coverage ensures uniform heat distribution right up to the valve flanges.
- 100% Hydro-Tested Jacket: Every jacket enclosure undergoes separate pressure testing to ensure leak-free heating fluid containment.
- Heavy-Duty Construction: Engineered with oversized flanges and reinforced stems to resist thermal expansion and stress.
Reliable Supply Chain Across India & Abroad
FlowBiz serves as a trusted manufacturer and exporter of specialty industrial valves. We provide rapid delivery and technical support in:
- Gujarat: Key industrial hubs including Ahmedabad (Odhav, Vatva, Naroda, Sanand), Vapi, Bharuch, Dahej, Gandhidham, and Surat (Hazira, Sachin).
- Maharashtra: Major industrial centers such as Mumbai, Pune, Nashik, Nagpur, and Aurangabad.
- International: Exporting specialized jacketed and high-pressure valve solutions across Africa and global markets.
