High-Purity Tri-Clover (Tri-Clamp) Ball Valves by FlowBiz – Hygienic Flow Isolation
In sanitary industries like pharmaceuticals, biotechnology, food & beverage, and dairy, maintaining a crevice-free, contamination-free piping system is critical. FlowBiz Tri-Clover Ball Valves (Tri-Clamp Ball Valves) are high-purity sanitary valves designed specifically for applications requiring rapid disassembly, thorough cleaning (CIP/SIP), and zero bacterial entrapment.
Manufactured with high-grade stainless steel (SS316 / SS316L) featuring mirror-polished internal surfaces, these valves connect seamlessly into hygienic piping networks using quick-release Tri-Clover clamps. FlowBiz sanitary ball valves ensure smooth quarter-turn fluid control with minimal flow resistance and total hygiene.
Technical Specifications & Features
FlowBiz Tri-Clover Ball Valves are engineered to strictly adhere to international hygienic and sanitary standards:
- Valve Type: Sanitary / Hygienic Tri-Clover (Tri-Clamp) Ball Valve
- End Connections: Tri-Clover (TC) Ferrule Ends / Tri-Clamp Ends (ISO, SMS, 3A standard)
- Surface Finish: Electro-polished / Internal surface finish Ra ≤ 0.4 µm (Mirror Finish)
- Material of Construction (MOC): Stainless Steel (ASTM A351 CF8M / SS304 / SS316 / SS316L)
- Sealing & Cavity: Food-grade PTFE / Cavity Filled Seats (to eliminate product buildup around the ball)
- Operation: Ergonomic manual lever handle with red vinyl insulation sleeve and stem locking mechanism
- Pressure Rating: PN10 / PN16 / 1000 WOG
Technical Overview Table
Technical Parameter | Specification Details |
Manufacturer | FlowBiz Exports Pvt. Ltd. |
Product Type | Tri-Clover (Tri-Clamp) Ball Valve |
Size Range | 1/2" (DN15) to 4" (DN100) |
End Connection | Tri-Clamp (TC) Ferrule Ends |
Body Material | SS304 / SS316 / SS316L |
Seat & Seal | Food Grade PTFE / Cavity Filled PTFE / Silicone / EPDM |
Operating Pressure | Up to 10 Bar (150 PSI) |
Design Standards | 3A Sanitary Standards / DIN / SMS / ISO 2852 |
Key Applications Across Industries
FlowBiz Tri-Clover Ball Valves deliver absolute cleanliness across sensitive sanitary process loops:
- Pharmaceutical & Biotech: Ideal for WFI (Water for Injection) systems, sterile processing lines, and fermentation tanks.
- Food & Beverage Processing: Controls syrup, fruit juices, edible oils, and alcohol lines without flavor contamination.
- Dairy & Ice Cream Plants: Ensures leak-tight flow for milk, cream, and liquid dairy culture networks.
- Cosmetics & Personal Care: Handles lotions, creams, and gels requiring high-purity fluid transfer.
Why Choose FlowBiz Exports Pvt. Ltd.?
FlowBiz sanitary valve engineering guarantees optimal hygiene and long service life:
- Quick Disassembly: TC end design allows tool-free removal from the pipeline for fast manual cleaning and gasket inspection.
- Zero Contamination: Precision cavity-fillers prevent residual fluids from trapping inside the valve body, preventing bacterial growth.
- 100% Quality Inspected: Hydrostatically and pneumatically tested for shell strength and seat tightness per ASME BPE and API 598.
Reliable Supply Chain Across India & Abroad
FlowBiz serves as a trusted manufacturer and exporter of sanitary and industrial valves. We provide rapid delivery and technical support in:
- Gujarat: Key industrial hubs including Ahmedabad (Odhav, Vatva, Naroda, Sanand), Vapi, Bharuch, Dahej, Gandhidham, and Surat (Hazira, Sachin).
- Maharashtra: Major industrial centers such as Mumbai, Pune, Nashik, Nagpur, and Aurangabad.
- International: Exporting high-purity hygienic valves and flow control equipment across Africa and global markets.
