Double Eccentric Offset Disc Butterfly Valve: High-Performance Engineering by FlowBiz Exports

In modern fluid dynamics, the Double Eccentric Butterfly Valve (also known as the Double Offset Valve) is the superior choice for high-pressure systems and large-diameter pipelines. FlowBiz Exports Pvt Ltd is a leading Double Eccentric Butterfly Valve manufacturer in India, providing state-of-the-art engineering solutions that ensure zero-leakage and extended service life.

Understanding the Double Eccentric (Double Offset) Design

The "Double Eccentric" design features two distinct offsets in the valve geometry that prevent friction between the disc and the seat.

  1. Offset 1: The shaft is located behind the centerline of the sealing surface.
  2. Offset 2: The shaft is located to one side of the pipe/valve centerline.

Why FlowBiz Offset Valves Lead the Industry:

  • Friction-Free Sealing: The disc "lifts" off the seat immediately upon opening, drastically reducing seat wear and extending the valve's operational life.
  • Low Operating Torque: The offset geometry reduces the force required to open and close the valve, making it ideal for automation.
  • Tight Shut-Off: Our PTFE seats combined with FEP/PFA lining offer a "bubble-tight" seal even in corrosive environments.
  • Full Flow Downstream: Designed for multiple ON/OFF operations in extensive pipelines with minimal pressure drop.

Technical Specifications: Model BOD

FlowBiz ensures every valve is built to handle extreme industrial stressors.

Parameter

Specification Details

Model

BOD (Double Offset Design)

Size Range

4" to 48" (DN100 to DN1200)

Body Materials

Cast Iron, Cast Steel, Ductile Iron, CF8, CF8M

Disc Materials

Cast Steel, CF8, CF8M

Lining/Sleeve

FEP / PFA (High Chemical Resistance)

Seat Material

PTFE (Virgin or Reinforced)

Pressure Rating

PN 10 (PN 16 available on request)

Temperature

Up to 200°C (depending on MOC)

Operation

Manual (Lever Handle / Gearbox)

Strategic Applications

FlowBiz Double Offset Butterfly Valves are designed for critical sectors where reliability is non-negotiable:

  • Water Treatment & Desalination: Highly resistant to salt-water corrosion.
  • Chemical & Pharmaceutical: Utilizing PFA/FEP lining for aggressive media.
  • HVAC & Power Plants: Efficiently managing large volumes of cooling water.
  • Oil & Gas: Reliable isolation for mid-stream and down-stream pipelines.

India’s Trusted Supply Network

FlowBiz Exports Pvt Ltd manages a robust distribution infrastructure, ensuring rapid delivery to major industrial hubs in Gujarat, Maharashtra, and across the nation.

Manufacturing & Supply Hubs:

  • Gujarat: Ahmedabad, Vapi, Valsad, Surat, Gandhidham, Kutch, Ankleshwar, Bharuch.
  • Maharashtra: Mumbai, Nashik, Pune, Thane, Aurangabad, Satara, Nagpur, Kolhapur.
  • Pan-India: Indore, Bhopal, Chennai, Coimbatore, Salem, and beyond.

Upgrade your pipeline integrity with the industry’s most reliable Double Eccentric Butterfly Valves. Contact FlowBiz Exports Pvt Ltd today for technical consultations, 2D/3D drawings, and a free competitive quote.
